AMICI DI BICI

FRAME: Crossway TFS III, aluminium, 700x50C max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard, MUK 5 Hanger

FRAME SIZES: S, M, L

FORK: Suntour NCX-D LO, Coil, 63mm suspension travel, Lockout, 700x50C max. wheelsize

RIMS: Merida Comp TK, 20mm inner width, 17mm height, material: aluminium

HUBS: Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock

TYRES: Maxxis Overdrive Excel 700x40C, wire, reflective stripe, Silkshild

CRANKS: FSA Alfa Drive, 48-36-26 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL

BOTTOM BRACKET: FSA TH-7420ST Cartridge Bearing

CASSETTE: Shimano HG500, 11-34 teeth, 10 speed

CHAIN: KMC X10

SHIFTERS: Shimano Deore

FRONT DERAILLEUR: Shimano Deore

REAR DERAILLEUR: Shimano Deore

BRAKE LEVERS: Tektro M275

BRAKES: Tektro M275, 2 piston, Shimano RT10 160 mm rotors

HEADSET: Merida M2346 Neck

STEM: Merida Comp TK, material: aluminium, 31.8mm diameter, adjustable, 80 mm-XXS/XS/S, 90 mm-M/L, 100 mm-XL

HANDLEBAR: Merida Comp CC, material: aluminium, 660mm width, 25mm rise

GRIPS: Merida Expert EC

SEAT POST: Merida TK, 30.9mm diameter, 10mm setback, 40mm seatpost suspension travel

SEAT CLAMP: Merida Expert

SADDLE: Merida Cross Sport

PEDALS: VP VPE-891

Frame
Canyon Grail AL Disc
Axle dimension: 12x142 mm
Tyre Clearance: 42 mm
Material: Aluminium (AL)
Fork
Canyon FK0070 CF Disc
Material: Carbon
Steerer: 1 1/4"
Axle Dimension: 12 x 100 mm
Brake Mount: Flat Mount
Drivetrain
Battery
SRAM eTap Powerpack 1BY
Removable battery for wireless eTap derailleurs.
Charge time: less than 60 minutes.
Rear Derailleur
SRAM Rival XPLR eTap AXS
12-speed rear derailleur, optimised for gravel riding. With spring clutch for precise shifting and excellent chain stability, and larger X-SYNC pulley wheels for greater durability and efficiency.
Max. cassette size: 44 teeth
Cassette
SRAM Rival XPLR XG-1251, 12-speed, 10-44T
Gravel-specific 12-speed cassette with X-Range gearing for a larger range with smaller gaps between gears.
Gear range: 10-44T
Crank
SRAM Rival D1 Wide, 40T
Number of chainrings: 1
Bottom bracket
SRAM Pressfit DUB Wide
Pressfit BB compatible with SRAM DUB axles.
BB-frame interface: 86.5 mm
Weight: 72 g
Chain
SRAM RIVAL D1 12s
12-speed chain with flattop technology for narrower design, quieter operation, and increased strength and durability.
Brakes
Shift-/ Brake Lever
SRAM Rival eTap AXS 2s
Left-hand shifter with hood shape optimised to fit hands of all sizes, for comfortable and controlled braking from any position. With wireless shifting, contact point adjustment, reach adjust.
Shift-/ Brake Lever
SRAM Rival eTap AXS 12s
Right-hand shifter with hood shape optimised to fit hands of all sizes, for comfortable and controlled braking from any position. With wireless shifting, contact point adjustment, reach adjust.
Brake Rotor
SRAM Paceline
Designed for optimal venting. With rounded edges for easier wheel installs.
Disc mount: centerlock
Weight: 155 g
Wheels
Wheel
DT Swiss Gravel LN
Rotor mount: Center Lock
rim height: 25 mm
Wheel
DT Swiss Gravel LN
Rotor mount: Center Lock
rim height: 25 mm
Tyre
Schwalbe G-One R, 40mm
High-end gravel race tyres for light gravel and asphalt.
Combining incredible smoothness, speed, and control.
Technology: tubeless-ready, V-Guard puncture protection.
Width: 40mm
Thru Axle
Canyon GP0197-01 Thru Axle 100X12
Axle dimensions: 12 x 100 mm
Thru Axle
Canyon GP0235-01 Thru Axle 142x12
Axle dimensions: 142 x 12 mm
Cockpit
Stem
Canyon V13
High-quality aluminium stem with square cross-sectional profile. A new handlebar clamp design increases torsional stiffness by up to 40%. Handlebar clamp diameter: 31.8 mm. Head tube diameter: 1 1/4".
Clamping diameter: 31,8 mm
Handlebar
Canyon HB0063
Clamping diameter: 31,8 mm
Width: 440 mm
Handlebar Tape
Canyon Ergospeed Gel
Bar tape with EVA foam and elastomer gel mix for optimal comfort.
Color: black
Seat
Saddle
Selle Italia Model X
Saddle with central cut-out and flexible wings for maximum comfort. Featuring durable Soft-Tek cover for maximum durability and scratch resistance.
Rail material: Manganese
Gender: Male
Seatpost
Canyon SP0043 VCLS CF
Material: Carbon
Setback: 20 mm
Technology: VCLS

frame Alpha aluminium 100 Series

Bontrager Paradigm - Bontrager R1 Hard Case Lite 32 mm

Bontrager Verse Comp - Bontrager Comp 6061

Bontrager Comp VR-C - Bontrager Elite

ventielen 48 - 60 mm


materiaal 420D Ribstop

Maximaal wattage van 1800 watt
Vermogensnauwkeurigheid: +/- 2,5%
Simuleert stijgingspercentages tot max 16%
ERG-modus aanwezig
Verzendt draadloos gegevens via Bluetooth FTMS en Ant+ FEC
Gewicht vliegwiel: 4,7 kg
Productgewicht: 15 kg
Maximaal gewicht van de fietser: 120 kg
Geluid: 52 dB bij 250 watt
Body: Hyperglide
Compatibel met snelspanner (130/135 mm) en steekas (12×142/12×148) via meegeleverde adapters
2 jaar garantie onder voorwaarden

27.5+" , 29", 27.5"'

frame Grade 9 Titanium

Average frame weight: 1,280 g (S)
Headtube: IS41/28.6 IS52/40 (integrated/tapered)
Seatpost: 27.2 mm (31.8mm seat clamp)
Bottom Bracket: BB386
Dropouts: 142 x 12mm axle flat mount with disc brake
Fork: RockShox FS-Rudy-UCI-A1
Wheel size: 700c or 650b
Maximum Tire Width: 700x40c, 700x45c, or 650Bx47c and 27.5″ x 2.1″ (tire width may vary depending on the manufacturer and tire pressure)
Available in Gravel / Adventure geometry in the following standard sizes: S, M, L
Custom geometry/sizing also available ($500 USD upcharge)
Frame compatible with all Shimano, SRAM, and Campagnolo groupsets featuring disc brakes
Lifetime warranty on frame (against manufacturers defects)

vork carbon
Shimano 105 Di2 R7100, 50/34,

cassette 11-34, 140/160 mm
Forza Levanto Gravel carbon - Vittoria Corsa N.EXT 32 mm
Zadel/zadelpen: Selle Italia XLR/Forza Cirrus Gravel
Stuur/stuurpen: Forza Cirrus Integrated Pro Gravel

48 Limitless Aero disc

Salsa Fargo Geometry

Size	XS	SM	MD	LG	XL
A. Effective Top Tube	520	540	565	590	620
B. Stand Over	692	734	781	823	861
C. Reach	350	364	368	385	409
D. Stack	594	615	643	671	690
E. Total Seat Tube Length	355.6	406.4	457.2	508	558.8
F. Headtube Length	90	110	140	170	190
G. Headtube Angle	68.5	69	69	69	69
H. Seat Tube Angle	74	74	73	73	73
I. BB Drop	70	70	70	70	70
K. Chainstay Length	445462	445462	445462	445462	445462
L. Fork Length Axle to Crown	480	480	480	480	480
M. Fork Offset	51	51	51	51	51
N. Wheelbase	10501067	10671084	10831100	11101127	11411158
Recommended Rider Height	150cm160cm	160cm175cm	173cm183cm	180cm191cm	188cmUP
