• Frame | ALX 6061 Alloy, IFS Suspension Design, 170mm Travel
• Fork | Fox 38 Performance Series, GRIP Damper, 44mm Offset, 170mm Travel
• Shock | Fox Float X2 Performance Elite, 205x65mm
• Wheels | Shimano XT Hubs & Entity XL3 Alloy Rims, 35mm Inner Width
• Tyres | Schwalbe Magic Mary, ADDIX Soft Rubber, Super Gravity Casings, 2.6in Front & Rear
• Drivetrain | Shimano XT 1×12 w/32T Crankset & Deore 10-51T Cassette
• Brakes | SRAM Code R w/200mm Centerline Rotors
• Bar | Race Face Aeffect R, 20mm Rise, 780mm Width
• Stem | Race Face Aeffect R, 40mm Length
• Seatpost | TranzX, 30.9mm Diameter, Travel: 150mm (S-M), 170mm (L-XL)
• Saddle | Entity Xtend

• Frameset: Ridley Noah Disc Essential
• Shifters: SRAM Rival eTap AXS
• Derailleurs: SRAM Rival eTap AXS 48/35
•  Forza Levanto DB carbon, 38mm deep -  Vittoria Corsa G2.0, 700x25mm
• Brakes: SRAM Rival hydraulic disc
• Cockpit: Noah Fast Aero one-piece carbon handlebar and stem
• Seatpost: Ridley D-shaped carbon
• Saddle: Selle Italia XR

Ratio Direct-Mount XX1 mechanical derailleur prototype ?

Technical specifications

Battery voltage: 3.6V

Max. Ah: 3Ah

Max. pressure: 10bar

Max. pressure: 150psi

Max. pressure: 1,030kPa

Max. output volume: 10 l/min

Hose length: 0.2m

Tool dimensions (L x W x H): 265 x 123 x 87mm

Weight: 0.4kg

In the box:

French-valve adaptor

Ball needle

Volume adaptor

USB cable

Textile bag

• Frameset: Roadmachine 01 AMP X Premium Carbon with Tuned Compliance Concept Endurance
• Motor: TQ-HPR50
• Battery: TQ 360Wh
• Drivetrain: SRAM Force XPLR eTap AXS
• Wheelset: CRD-400 SL Carbon, tubeless-ready, 23mm
• Tyres: Pirelli Cinturato Gravel H, 700x35mm
• Seatpost: Roadmachine 01 AMP X Premium Carbon D-Shaped seatpost
• Handlebar: BMC RAB 02, Ergo Top Shape, Compact Bend
• Saddle: Fizik Terra Argo X5 (150mm)

• Frameset: Roadmachine 01 AMP X Premium Carbon with Tuned Compliance Concept Endurance
• Motor: TQ-HPR50
• Battery: TQ 360Wh
• Drivetrain: SRAM Rival XPLR eTap AXS
• Wheelset: XRD-522, tubeless-ready, 22mm
• Tyres: Pirelli Cinturato Gravel H, 700x35mm
• Seatpost: Roadmachine 01 AMP X Premium Carbon D-Shaped seatpost
• Handlebar: BMC RAB 02, Ergo Top Shape, Compact Bend
• Saddle: Fizik Terra Argo X5 (150mm)

Yeti SB140 T2

• Fork: Fox Factory 36 FIT 150mm
• Shock: Fox Factory Float DPS
• Drivetrain: SRAM X01 Eagle
• Brakes: SRAM G2 RSC
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Aggressor EXO 2.3 (r)
• Yeti SB140 T3

• Fork: Fox Factory 36 FIT 150mm
• Shock: Fox Factory Float DPS
• Drivetrain: SRAM X01 Eagle AXS
• Brakes: SRAM G2 RSC
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Aggressor EXO 2.3 (r)
• Yeti SB140 T4

• Fork: Fox Factory 36 FIT 150mm
• Shock: Fox Factory Float DPS
• Drivetrain: SRAM XX1 Eagle AXS
• Brakes: SRAM G2 Ultimate
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Aggressor EXO 2.3 (r)
• Yeti SB140 C1

• Fork: Fox Performance 36 150mm
• Shock: Fox Performance Float DPS
• Drivetrain: Shimano SLX
• Brakes: Shimano SLX 4 piston
• Wheels: Crankbrothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Aggressor EXO 2.3 (r)
• Yeti SB140 C2

• Fork: Fox Performance 36 150mm
• Shock: Fox Performance Float DPS
• Drivetrain: SRAM GX Eagle
• Brakes: SRAM G2 R
• Wheels: Crankbrothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Aggressor EXO 2.3 (r)

Yeti SB140 TLR T1

• Fork: Fox Factory 36 GRIP 160mm
• Shock: Fox Factory Float X
• Drivetrain: SRAM X01 Eagle
• Brakes: SRAM Code RSC
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)
• Yeti SB140 TLR T3

• Fork: Fox Factory 36 GRIP 160mm
• Shock: Fox Factory Float X
• Drivetrain: SRAM XX1 Eagle AXS
• Brakes: SRAM Code RSC
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)
• Yeti SB140 TLR T4

• Fork: Fox Factory 36 GRIP 160mm
• Shock: Fox Factory Float X
• Drivetrain: SRAM XX1 Eagle AXS
• Brakes: SRAM Code RSC
• Wheels: DT Swiss XM1700
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)
• Yeti SB140 CLR C1

• Fork: Fox Performance 36 160mm
• Shock: Fox Performance Float X
• Drivetrain: Shimano SLX
• Brakes: Shimano SLX 4-piston
• Wheels: Crankbrothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)
• Yeti SB140 CLR C2

• Fork: Fox Performance 36 160mm
• Shock: Fox Performance Float X
• Drivetrain: SRAM GX Eagle
• Brakes: SRAM Code R
• Wheels: Crankbrothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)
• Yeti SB140 CLR C3

• Fork: Fox Performance 36 160mm
• Shock: Fox Performance Float X
• Drivetrain: SRAM GX Eagle AXS
• Brakes: SRAM Code R
• Wheels: Crankbrothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5 (f), Maxxis Minion DHR II 2.4 EXO (r)

Frame: UD Toray T500 and T700 Carbon with mudguard, rack and 3 bottle cage mounts

Colour: Bronze

Sizes: S, M, L, XL

Fork: Carbon UD 1-1/8" to 1-1/2" with mudguard eyelets and front rack mounts

Brake Type: For Flat Mount Disc Brakes

Cable Routing: Internal

Bottom Bracket: BSA Threaded

Max Tyre Clearance: 700 x 45c / 650b x 2.1

Weight: 1300g (frame) / 500g (fork)

Drive Train: 1x13 speed Disc Brake

Shifters: Campagnolo EKAR 1x13

Rear Derailleur: Campagnolo EKAR

Brakes: Campagnolo EKAR Flat Mount Disc

Rotors: Campagnolo AFS 160mm (front) / 140mm (rear)

Cassette: Campagnolo EKAR 13x 9-42T

Chainset: Campagnolo EKAR 13x 40T

Chain: Campagnolo EKAR 1x13x

Wheels: Miche Graff N3W -  Schwalbe CX Comp 700x38

Handlebar: Tifosi Alloy Gravel Bar

Seatpost: Tifosi Alloy 27.2mm

Stem: Tifosi Alloy

Saddle: Selle Italia Model X Superflow

Yeti SB120 T1

• Fork: Fox 34 Factory GRIP2 130mm
• Shock: Fox Float DPS Factory
• Drivetrain: SRAM GX Eagle
• Brakes: SRAM G2 RSC
• Wheels: DT Swiss XM 1700
• Tyres: Maxxis Minion DHF EXO 2.5in (f), Maxxis Aggressor EXO 2.3in (r)

• Fork: Fox 34 Factory GRIP2 130mm
• Shock: Fox Float DPS Factory
• Drivetrain: SRAM X01/XX1 AXS
• Brakes: SRAM G2 RSC
• Wheels: DT Swiss XM 1700
• Tyres: Maxxis Minion DHF EXO 2.5in (f), Maxxis Aggressor EXO 2.3in (r)

• Fork: Fox 34 Factory Fit4 130mm
• Shock: Fox Float DPS Factory
• Drivetrain: SRAM XX1 AXS
• Brakes: SRAM Level Ultimate
• Wheels: DT Swiss EXC 1501
• Tyres: Maxxis Rekon EXO 2.4in (f), Maxxis Rekon Race EXO 2.35in (r)

Yeti SB120 C1

• Fork: Fox 34 Performance 130mm
• Shock: Fox Float DPS Performance
• Drivetrain: Shimano SLX
• Brakes: Shimano SLX
• Wheels: Crank Brothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5in (f), Maxxis Aggressor EXO 2.3in (r)

Yeti SB120 C2

• Fork: Fox 34 Performance 130mm
• Shock: Fox Float DPS Performance
• Drivetrain: SRAM GX Eagle
• Brakes: SRAM G2 R
• Wheels: Crank Brothers Synthesis Enduro
• Tyres: Maxxis Minion DHF EXO 2.5in (f), Maxxis Aggressor EXO 2.3in (r)

GPS Chipset U-blox 7

Touchscreen

Color Display (sunlight readable)

Display Resolution 240X400

Display Size 2.8"

Width (mm) 58 - Height (mm) 100 - Depth (mm) 22 - Weight (gr) 133

Memory 16 GB

Battery up to 17h

Buzzer Instructions

Light Sensor

IP Rating (Waterproof) IPX7

WIFI

Bluetooth 4.2

Barometric Altitude

SoftwareCustomizable Dashboard

WeJoin™

NeverMiss™

Mark Place with Recording Data Upload to MioShare™

Detailed History

BIKE POI-LIST

Surprise Me™ Loop

Surprise Me™ A to B

Importing Tracks

Komoot Tracks

RouteYou Tracks

STRAVA Route (STRAVA Premium account)

Shimano STEPS

* Shimano STEPS series supported: SC-E6100 / SC-E7000 / SC-EM800 / EW-EN100.

Save Favorite Location

Map with Elevation

Where Am I Function

Strava Upload

Turn-by-Turn to Track Start Point

Voice Guidance (by smartphone App)

Block Roads For Detour

Fitness Function

Incoming Message Alert

Incoming Call Alert

Wireless Data Sync

Maps Pre-installed

Node Option(knooppunten) (Node Network)

Climb info

Free Map Updates Lifespan of device (by smartphone App)

OSM

Cloud Service MioShare™

Smartphone App (iOS/Android) MioShare™ App

• 3T Strada ICR Force AXS 2×12, €6.199
• 3T Strada ICR Rival XPLR 1×12, €5.199
• 3T Strada ICR Rival AXS 2×12, €5.499
• 3T Strada ICR Red AXS 1×12, €7.499

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 12x148mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: Fox Float X Performance, custom tuned (Metric trunnion 210x50mm)
• Fork: Marzocchi Bomber Z1, RAIL, 140mm travel
• Drivetrain: Shimano XT M8100 / SLX M7100 mix with FSA GRID crankset
• Brakes: Shimano BR-MT420 4-piston calipers with BL-M4100 levers
• Wheels/tyres: Marin Aluminium Double Wall / Maxxis Assegai MaxxTerra EXO 29×2.5in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin Grizzly Lock On
• Seatpost/saddle: TranzX YSP23JL (S: 150mm, M and L: 170mm, XL: 200mm travel) / Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 12x148mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: RockShox Deluxe Select RT, custom tuned (Metric trunnion 210x50mm)
• Fork: Marzocchi Bomber Z2, RAIL, 140mm travel
• Drivetrain: Shimano Deore M6100 with FSA Comet crankset
• Brakes: Shimano BR-MT200 calipers with BL-M200 levers
• Wheels/tyres: Marin Aluminium Double Wall on Shimano HB-MT410B hubs/ Vee Tire Flow SNAP Tackee Compound 29×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin Grizzly Lock On
• Seatpost/saddle: TranzX YSP23JL (S: 150mm, M, L and XL: 170mm travel) / Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 9x141mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: X-Fusion O2 Pro R, custom tuned (Metric trunnion 210x50mm)
• Fork: X-Fusion Slide Boost RC, 140mm travel
• Drivetrain: Shimano Deore M5100 with Marin crankset
• Brakes: Shimano BR-MT200 calipers with BL-M200 levers
• Wheels/tyres: Marin Aluminium Double Wall on Shimano HB-MT200/MT400 hubs/ Vee Tire Crown Gem Dual Control Compound 29×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin MTN
• Seatpost/saddle: Marin/Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 12x148mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: Fox Float X Performance, custom tuned (Metric trunnion 210x50mm)
• Fork: Marzocchi Bomber Z1, RAIL, 140mm travel
• Drivetrain: Shimano XT M8100 / SLX M7100 mix with FSA GRID crankset
• Brakes: Shimano BR-MT420 4-piston calipers with BL-M4100 levers
• Wheels/tyres: Marin Aluminium Double Wall on Shimano HB-MT410B hubs/ Maxxis Assegai MaxxTerra EXO 27.5×2.5in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin Grizzle Lock On
• Seatpost/saddle: TranzX YSP23JL (S: 150mm, M and L: 170mm, XL: 200mm travel) / Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 12x148mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: RockShox Deluxe Select RT, custom tuned (Metric trunnion 210x50mm)
• Fork: Marzocchi Bomber Z2, RAIL, 140mm travel
• Drivetrain: Shimano Deore M6100 with FSA Comet crankset
• Brakes: Shimano BR-MT200 calipers with BL-M200 levers
• Wheels/tyres: Marin Aluminium Double Wall on Shimano HB-MT410B hubs/ Vee Tire Flow SNAP Tackee Compound 27.5×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin Grizzly Lock On
• Seatpost/saddle: TranzX YSP23JL (S: 150mm, M, L and XL: 170mm travel) / Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, Boost 9x141mm axle, 73mm BSA bottom bracket, ISCG05 chain device tabs
• Shock: X-Fusion O2 Pro R, custom tuned (Metric trunnion 210x50mm)
• Fork: X-Fusion Slide Boost RC, 140mm travel
• Drivetrain: Shimano Deore M5100 with SunRace cassette and Marin crankset
• Brakes: Shimano BR-MT200 calipers with BL-M200 levers
• Wheels/tyres: Marin Aluminium Double Wall on Shimano HB-MT200/MT400 hubs/ Vee Tire Crown Gem Dual Control Compound 27.5×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin MTN
• Seatpost/saddle: Marin/Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, 135mm dropout (upgradable to 12×142), 73mm BSA bottom bracket
• Shock: X-Fusion O2 Pro R, custom tuned (Metric trunnion 190x51mm)
• Fork: X-Fusion Velvet RLC, 130mm travel
• Drivetrain: Shimano Deore M5100 with SunRace cassette and Marin crankset
• Brakes: Shimano BR-MT201 calipers with BL-M201 levers
• Wheels/tyres: Marin Aluminium Double Wall/ Vee Tire Flow SNAP Tackee Compound 26×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin MTN
• Seatpost/saddle: Marin/Marin Speed Concept

• Frame: Series 3 6061 aluminium, 130mm-travel MultiTrac Suspension, 135mm dropout (upgradable to 12×142), 73mm BSA bottom bracket
• Shock: X-Fusion O2 Pro R, custom tuned (Metric trunnion 190x51mm)
• Fork: X-Fusion Velvet RLC, 130mm travel
• Drivetrain: Shimano Deore M5100 with SunRace cassette and Marin crankset
• Brakes: Shimano BR-MT201 calipers with BL-M201 levers
• Wheels/tyres: Marin Aluminium Double Wall/ Vee Tire Flow SNAP Tackee Compound 24×2.35in front and rear
• Bar/stem/grips: Marin Mini-Riser 780mm/Marin 3D Forged Alloy/Marin MTN
• Seatpost/saddle: Marin/Marin Speed Concept

Castelli-exclusive GORE-TEX INFINIUM™ WINDSTOPPER® 205 Warm brushed water-resistant fabric on front-facing surfaces

GORE-TEX INFINIUM™ WINDSTOPPER® 203 Stretch on rear-facing surfaces for greater stretch and breathability

Taped shoulder seams for extra rain protection

Top- and bottom-opening YKK® Vislon® zipper for easy sliding, covered for additional wind and rain protection

Zippered ventilation opening on side of chest

3 rear pockets

Reflective panel at bottom of pockets
