Orbea 2021 Gain e-road
Orbea Gain M10i
- Frame: Orbea Gain Carbon OMR
- Fork: Gain OMR carbon fork
- Crankset: Shimano Dura-Ace 9100 34x50t
- Headset: Acros Alloy 1-1/2in Internal Cable Routing
- Handlebar: OC2 Road Carbon, reach 80mm, drop 125mm
- Stem: Orbea ICR -8º
- Shifters: Shimano R9170
- Brakes: Shimano R9170 Hydraulic Disc
- Rear Derailleur: Shimano Dura-Ace 9150 Di2
- Front Derailleur: Shimano Dura-Ace 9150 Di2
- Chain: Shimano HG 901
- Wheels: OC2 Carbon 42 Tubeless Ready
- Cassette: Shimano Dura-Ace R9100 11-30t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Fizik Antares R5 Versus EVO Regular
- Front light: COB Led, 60 Lumen
- Motor: Ebikemotion X35 Plus 25kmh
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M20i
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano Ultegra R8000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC2 Road, reach 80mm, drop 125mm
- Stem: Orbea ICR -8º
- Shifters: Shimano ST-8070
- Brakes: Shimano R8070 Hydraulic Disc
- Rear Derailleur: Shimano Ultegra Di2 R8050 GS
- Front Derailleur: Shimano Ultegra Di2 R8050
- Chain: KMC X11
- Wheels: OC2 Carbon 42 Tubeless Ready
- Cassette: Shimano Ultegra R8000 11-32t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Motor: Ebikemotion X35 Plus 25kmh
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M20
- rame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano Ultegra R8000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC2 Road, reach 80mm, drop 125mm
- Stem: Orbea ICR -8º
- Shifters: Shimano ST-8020
- Brakes: Shimano R8070 Hydraulic Disc
- Rear Derailleur: Shimano Ultegra R8000 GS
- Front Derailleur: Shimano Ultegra R8000
- Chain: KMC X11
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano Ultegra R8000 11-32t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M20 1
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano GRX RX810 40t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC1 All Road, reach 80mm, drop 125mm, flare 12º
- Stem: Orbea ICR -8º
- Shifters: Shimano ST-RX810
- Brakes: Shimano ST-RX810
- Rear Derailleur: Shimano RX812 GS
- Chain: Shimano HG 601
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano CS-M8000 11-40t 11-Speed
- Tyres: Schwalbe G-ONE Bite, 700x38C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M20F
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano Ultegra R8000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: Alloy 31.8mm 12mm Rise 700mm
- Stem: Orbea ICR -8º
- Shifters: Shimano SL-SR700
- Brakes: Shimano XT M8100 Hydraulic Disc
- Rear Derailleur: Shimano Ultegra R8000 GS
- Front Derailleur: Shimano Ultegra R8000
- Chain: KMC X11
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano Ultegra R8000 11-32t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen,
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote1: Ebikemotion iWoc ONE
- Remote2: Ebikemotion iWoc TRIO
- Charger: Ebikemotion X35
Orbea Gain M30
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano 105 R7000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC2 Road, reach 80mm, drop 125mm
- Stem: Orbea ICR -8º
- Shifters: Shimano ST-7020
- Brakes: Shimano R7070 Hydraulic Disc
- Rear Derailleur: Shimano 105 R7000 GS
- Front Derailleur: Shimano 105 R7000
- Chain: KMC X11
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano 105 R7000 11-32t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen,
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M30 1X
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano GRX RX600 40t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC1 All Road, reach 80mm, drop 125mm, flare 12º
- Stem: Orbea ICR -8º
- Shifters: Shimano ST-RX600
- Brakes: Shimano RX400 Hydraulic disc
- Rear Derailleur: Shimano RX812 GS
- Chain: Shimano HG 601
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano CS-M7000 11-40t 11-Speed
- Tyres: Schwalbe G-ONE Bite, 700x38C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Front light: COB Led, 60 Lumen
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain M30F
- Frame: Orbea Gain Carbon OMR monocoque
- Fork: Gain OMR carbon
- Crankset: Shimano 105 R7000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: Alloy 31.8mm 12mm Rise 700mm
- Stem: Orbea ICR -8º
- Shifters: Shimano SL-SR700
- Brakes: Shimano SLX M7100 Hydraulic Disc
- Rear Derailleur: Shimano 105 R7000 GS
- Front Derailleur: Shimano 105 R7000
- Chain: KMC X11
- Wheels: FULCRUM E-Racing 900
- Cassette: Shimano 105 R7000 11-32t 11-Speed
- Tyres: Schwalbe ONE 700x30C
- Seatpost: OC2 Carbon 27.2 Offset 20
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: Ebikemotion Pulsar One monochrome ANT+ LEV
- Remote1: Ebikemotion iWoc ONE
- Remote2: Ebikemotion iWoc TRIO
- Charger: Ebikemotion X35
Orbea Gain D20
- Frame: Orbea Gain Hydro 6061 Hydroformed Aluminium
- Fork: Gain Hydro carbon
- Crankset: Shimano Ultegra R8000 34x50t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC2 Road, reach 80mm, drop 125mm
- Stem: OC1 31.8mm interface -6º
- Shifters: Shimano ST-8020
- Brakes: Shimano R8070 Hydraulic Disc
- Rear Derailleur: Shimano Ultegra R8000 GS
- Front Derailleur: Shimano Ultegra R8000
- Chain: KMC X11
- Wheels: Ready GR
- Cassette: Shimano Ultegra R8000 11-32t 11-Speed
- Tyres: Hutchinson Fusion 5 Performance TLR 700×30
- Seatpost: OC 27.2 Offset 0, for integrated light
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Rear light: Lezyne FENDER STVZO seatpost mounting 11 lumens
- Motor: Ebikemotion X35 Plus 25kmh
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: OC monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain D30 1X
- Frame: Orbea Gain Hydro 6061 Hydroformed Aluminium
- Fork: Gain Hydro carbon fork, full carbon
- Crankset: Shimano GRX RX600 40t
- Headset: Acros Alloy 1-1/2 Internal Cable Routing
- Handlebar: OC1 All Road, reach 80mm, drop 125mm, flare 12º
- Stem: OC1 31.8mm interface -6º
- Shifters: Shimano ST-RX600
- Brakes: Shimano RX400 Hydraulic disc
- Rear Derailleur: Shimano RX812 GS
- Chain: KMC X11
- Wheels: Ready GR
- Cassette: Shimano CS-M7000 11-40t 11-Speed
- Tyres: Schwalbe G-ONE Bite 700x38C
- Seatpost: OC 27.2 Offset 0, for integrated light
- Saddle: Selle Royal Asphalt GR
- Front light: COB Led, 60 Lumen
- Rear light: Lezyne FENDER STVZO seatpost mounting 11 lumens
- Motor: Ebikemotion X35 Plus 25kmh
- Battery: Ebikemotion 36V/6.9A 248Wh ANT+
- Display: OC monochrome ANT+ LEV
- Remote: Ebikemotion iWoc ONE
- Charger: Ebikemotion X35
Orbea Gain D30
|
