Frame Diamondback Release 29, 130mm Travel, Level Link Suspension Platform, Hydroformed Tubing, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5″ Tapered Headtube

Rear Shock – Suntour Edge R, 200x57mm, Rebound Adjust, 22.2mm Eyelet Width

Fork SR Suntour Aion 29″, 140mm Travel, Air Spring w/Rebound Adjust, 35mm Stanction, 1.5″ Alloy Taper Steerer, 110x15mm Thru-axle

Headset FSA No. 57 Sealed Cartridge

Cranks SRAM SX w/Steel 32T Direct Mount

Bottom Bracket SRAM Powerspline, 118/73

Rear Derailleur SRAM SX Eagle, 12 Speed

Shifter SRAM SX Eagle, 12 Speed

Cogset SRAM PG1210, 12 Speed, 11-50T

Chain SRAM SX Eagle, 12 Speed

Front Hub 32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearing

Rear Hub 32h Alloy, Boost 148x12mm Thru-axle, 4 Sealed Cartridge Bearing, Cassette

Spokes 14g Stainless Steel

Rims Diamondback Blanchard 28R, Tubeless ready, 32h

Tires WTB Vigilante 27.5×2.3″, Wire Bead

Brakes TRP Slate X2, w/180mm Front / 180mm Rear Rotors

Pedals DB Alloy Platform w/Replaceable Pins

Handlebar DB35 Alloy, 760mm Wide, 15mm Rise, 35mm Bar Bore

Grips DB Lock-On Grip

Stem DB35 Alloy, 35mm Reach, 35mm Bar Bore

Seat WTB Koda Comp

Seat post TranzX YSP18JL, Internal Dropper, 31.6mm w/1x Remote, SM = 100mm, MD = 130mm, LG/XL = 150mm

Extras Tool Kit, DB Shock Pump, DB Mud Guard, Spare RD Hanger

Frame New Diamondback Sync’r Monocoque Carbon, Asymmetrical Chainstays, Internal Cable Routing, Tapered Headtube, Euro Standard Threaded BB, ISCG-05 Tabs, Internal Dropper Post Ready, 148x12mm Boost Hub Spacing, 29×2.4″, Post Mount Disc, w/ Replaceable Hanger

Fork Fox 34 Performance Float, 140mm of Travel, Grip 3 POS, 15mm Thru Axle

Headset FSA No-57E Taper 1.5 /1-1/8″ Standard Cups, Sealed Cartridge

Cranks SRAM NX, 32T Eagle Chainring

Bottom Bracket Truvativ Powerspline

Rear Derailleur SRAM GX Eagle, 12 Speed

Shifter SRAM GX Eagle 12 Speed X-Actuation Trigger

Cogset (Cassette/Freewheel) SRAM XG1275 Eagle, 12 Speed, 10-50T

Chain SRAM GX Eagle, 12 Speed

Front Hub 32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount

Rear Hub 32h Alloy, Boost 148x12mm Thru-axle, 5 Sealed Cartridge Bearing, for SRAM XD Cassette, w/ CNC Disc Mount

Spokes 14g Stainless Steel

Rims Diamondback Blanchard 32R, Tubeless compatible, 32h

Tires Maxxis Minion DHF 29×2.5″ EXO, TLR, Folding / Maxxis Minion DHR 29×2.4″ EXO, TLR, Folding

Brakes Shimano MT501 Hydraulic Disc, w/ 180mm Front and 160mm Rear Rotors

Brake Levers Shimano MT501 Hydraulic

Pedals DB4L Alloy Platform, Sealed Cartridge Bearings w/ Replaceable Pins

Handlebar Race Face Æffect 35, 20mm Rise, 780mm Wide, 35mm Bar Bore

Grips New DB “Flanged” Lock-on, 135mm Silcone

Stem Diamondback “Tec”, 35mm Reach, 35mm Bar Bore

Seat DB Sync’r Saddle

Seatpost X-Fusion Manic Dropper Post, 125mm (S,M) / 150mm (L,XL) of travel

Extras Tool Kit

Motor and Battery Specs:
Mahle ebike motion X35.
36V 250w – Max. Torque: 40N.m -Ratio: 14:1
Maximum Speed: 26kph
40Nm max torque, optimized for speeds between 15 and 25km
Battery- 250watt-hours, integrated in downtube (non-removable)
Compatible with 250wh extended-range external add-on battery
46-mile range with integrated battery

Integrated Remote:
ON, OFF & LIGHT Control
Displays Battery & Assist Level via RGB LED
